The Eyes
The Incredible Cameras We Use
DJI Matrice 4T:
Video Codec and Resolution
Video Coding Format: H.264/H.265
Coding Strategy: CBR, VBR
Resolution:
4K: 3840 x 2160@30fps
FHD: 1920 x 1080@30fps
Max Video Bitrate
H264: 60Mbps
H.265: 40Mbps
Wide:
Single: 12 MP/48 MP
Interval: 12 MP/48 MP
JPEG: 0.7/1/2/3/5/7/10/15/20/30/60 s
Smart Shooting: 12MP
Panorama: 12 MP (raw image):100 MP (stitched image)
Medium Tele Camera:
Single: 12 MP and 48 MP
Interval: 12 MP/48 MP
JPEG: 0.7/1/2/3/5/7/10/15/20/30/60 s
Smart Shooting: 12MP
Telephoto:
Single: 12 MP and 48
Open today | 12:00 am – 12:00 am |
EYES
Thermal
Spreading Wings 1000S+
Matrice 350 RTK
Thermal Imager
DJI Matrice 4T: uncooled vanadium oxide (VOx)
Resolution
DJI Matrice 4T: 640 × 512
Pixel Pitch
DJI Matrice 4T: 12 μm
Frame Rate
DJI Matrice 4T: 30 Hz
Lens
DJI Matrice 4T DFOV: 45°±0.3°
DJI Matrice 4T equivalent focal length: 53 mm
DJI Matrice 4T Aperture: f/1.0
DJI Matrice 4T Focus: 5 m to ∞
Sensitivity
DJI Matrice 4T: ≤50mk@F1.0
Temperature Measurement Method
DJI Matrice 4T: Spot Meter, Area Measurement
Temperature Measurement Range
DJI Matrice 4T:
High Gain Mode: -20℃ to 150℃ (-4°F to 302°F) ()
Low Gain Mode: 0℃ to 550℃ (32°F to 1022°F)
Palette
DJI Matrice 4T:
White Hot/Black Hot/Tint/Iron Red/Hot Iron/Arctic/Medical/Fulgurite/Rainbow 1/Rainbow 2
Photo Format
DJI Matrice 4T：JPEG (8bit)、 R-JPEG (16bit)
Video Resolution
DJI Matrice 4T:
1280 × 1024@30fps (Super Resolution enabled, Night Mode not activated)
Other conditions: 640 × 512@30fps
Video Bitrate
DJI Matrice 4T:
6.5Mbps (H.264 640 × 512@30fps)
5Mbps (H.265 640 × 512@30fps)
12Mbps (H.264 1280 × 1024@30fps)
8Mbps (H.265 1280 × 1024@30fps)
Video Format
DJI Matrice 4T：MP4Add a short description.
Matrice 350 RTK
Spreading Wings 1000S+
Matrice 350 RTK
4
The Matrice 350 RTK drone boasts a versatile camera system, including a wide camera, a zoom camera, and a thermal imaging camera. The wide camera has a 12MP 1/2" CMOS sensor with a 24mm equivalent focal length and 84° DFOV, capturing 4K/30fps video. The zoom camera features a 48MP 1/2" CMOS sensor, offering 5x-16x optical zoom, 200x max hybrid zoom, 8K photo resolution, and 4K/30fps video.The thermal camera has a 640x512 resolution, 30fps frame rate, and 40mm equivalent focal length, with measurement accuracy of ±2°C or ±2%
Spreading Wings 1000S+
Spreading Wings 1000S+
Spreading Wings 1000S+
The DJI Spreading Wings S1000+ is an octocopter designed for professional aerial photography and cinematography. Its large carrying capacity and compatibility with various gimbals allow it to support different camera setups. Here's a summary of its camera capabilities and related specs:Camera compatibility
- The S1000+ is compatible with DJI's entire line of Zenmuse Z15 camera gimbals.
- It's known to support cameras such as the Canon 5D Mark III and the Sony NEX-5N, especially when paired with the corresponding Zenmuse gimbals (e.g., Z15-5D III (HD) for the 5D Mark III).
- However, the S1000+ is not directly compatible with cameras like the Nikon D800, as the camera needs to be supported by the gimbal itself.
Gimbal specifications (example: Zenmuse Z15-5D III (HD) for Canon 5D Mark III)
- Axis: 3-axis stabilization.
- Rotation Range:
- Pan: ±360°
- Tilt: ±360°
- Roll: ±40°
- Controlled Angle Accuracy: ±0.01°
- Maximum Controlled Rotation Speed:
- Pan Axis: ±130°/s
- Tilt Axis: ±130°/s
- Roll Axis: ±30°/s
- Power Requirements: GCU: 4S to 12S LiPo
- Operating Temperature: 14 to 122°F (-10 to 50°C)
- Gimbal Weight: 3.1 lb (1.4 kg)
Key features for camera operation
- Low Gimbal Mounting Position: The S1000+'s design keeps the gimbal low, providing a wider range of shooting angles.
- Retractable Landing Gear: The landing gear retracts during flight, enabling unobstructed 360-degree camera views.
- Damping Design: The gimbal bracket is isolated from the main frame with dampers to reduce vibrations and ensure clearer footage.
- Video Downlink Compatibility: With compatible Zenmuse gimbals, the S1000+ offers video downlink for real-time camera view from the ground.
In essence, while the S1000+ itself doesn't have inherent camera specifications, its design, stability, and compatibility with DJI Zenmuse gimbals enable it to carry and operate various professional-grade DSLR and mirrorless cameras for aerial cinematography and photography.
